Model – MPW-5001-ACBK-P
ATX Version – ATX 12V Ver. 2.41
PFC – Active PFC
Input Voltage – 200-240V
Input Current – 3A
Input Frequency – 50-60Hz
Dimensions (L x W x H) – 140 x 150 x 86 mm
Fan Size – 120mm
Fan Bearing – Sleeve Fan
Efficiency ≥ 75% @ Typical Load
ErP 2014 Lot 3
 – Yes
Operating Temperature – 0-40°C
Power Good Signal – 100 – 500 ms
Hold Up Time ≥10ms at 100% load
MTBF >100,000 Hours
Protections – OVP / OPP / SCP / UVP / OTP / Inrush Protection
Regulatory – TUV, CE, CCC, EAC, UKCA
ATX 24 Pin Connectors – 1
EPS 4+4 Pin Connectors – 1
SATA & Peripheral 4 Pin Connectors – 6
PCI-e 6+2 Pin Connectors – 1
Series – Elite Series
Category – 500 to 750W
Modular – Non Modular
80 Plus – None 80 PLUS
Form Factor – ATX
Watts – 500W
